Eclipse Scientific BeamTool is a software designed primarily for professionals in non-destructive testing (NDT), particularly in ultrasonic testing and phased array ultrasonic testing (PAUT). The software is used for creating, visualizing, and optimizing ultrasonic inspection plans and beam setups. Below are some key features and aspects of BeamTool:
Key Features Of Eclipse Scientific BeamTool:
- Beam Path Simulation:
- Simulates ultrasonic beam paths for various inspection geometries, including welds, components, and complex parts.
- Supports both conventional UT and phased array UT setups.
- Probe and Wedge Setup:
- Allows users to define and configure probes, wedges, and other transducers.
- Simulates angles, beam coverage, and focal points.
- Inspection Coverage Visualization:
- Provides detailed visualization of beam coverage within a part or weld.
- Helps identify areas that may be missed during inspection.
- Focal Law Calculations:
- Generates and optimizes focal laws for phased array inspections.
- Supports multi-group configurations.
- Compatibility:
- Integrates with various ultrasonic inspection equipment.
- Exports data for use in equipment or reporting software.
- Code Compliance:
- Includes tools to ensure inspection setups comply with industry standards and codes (e.g., ASME, ISO).
- 3D Modeling and CAD Integration:
- Offers tools to import CAD models or create parts and welds directly within the software.
- Simulates inspection scenarios in 3D for better understanding.
- Reporting:
- Generates detailed inspection reports, including beam setups and coverage diagrams.
Applications
- Weld inspections.
- Corrosion mapping.
- Composite material testing.
- Complex component inspection in industries like aerospace, oil & gas, and manufacturing.
Benefits
- Enhanced accuracy and reliability of ultrasonic inspection setups.
- Reduction in setup time and trial-and-error processes.
- Improved documentation and compliance with inspection standards.
